H2GO® - Water Removal Purifier / Vacuum Dehydrator

POA

The H2GO® operates according to the principle of vacuum dewatering to separate dissolved water as well as dissolved gasses from hydraulic and lubrication fluids.

The H2GO® has an AquaSensor AS1000 to continuously monitor the water content and to control the unit. To increase the dewatering capacity a 3 stage heating system is employed, allowing use with higher viscosity fluids and cold fluids. The programmable logic controller PLC used in combination with a touch screen control panel guarantees simple and reliable handling.

Advantages

  • Extremely low residual water levels, gas levels in the operating fluids
  • Longer oil change intervals
  • Improved component service life
  • Greater machine availability
  • Reduction in the life cycle cost

Combining High-Efficiency Filtration for Total Purification

When used in combination with the HYDAC offline filtration systems, fluids that also have particulate contamination can be cleaned. Fluids that have a build-up of degradation products like Varnish (high MPC) can be treated in parallel with the Varnish Elimination Unit (VEU-AU).

By using specialised control and treatment solutions from HYDAC total oil conditioning is fast and efficient. The H2GO® forms an integral part of this program.

Product
H2GO® - Water Removal Purifier / Vacuum Dehydrator

Please contact the store to confirm stock availability near you

Recommended Products

FAQs

  • What is the function of the H2GO?

    The H2GO water removal purifier/vacuum dehydrator separates free and dissolved water and dissolved gases from hydraulic and lubrication fluids.

    On what principle does the H2GO operate?

    The H2GO operates on the principle of vacuum dewatering.

    What part does the H2GO’s Aqua Sensor AS1000 play?

    The H2GO’s Aqua Sensor AS1000 continuously monitors water content and controls the unit.

    How is H2GO use with higher viscosity and cold fluids permitted?

    A three-stage heating system is employed to increase dewatering capacity and permit H2GO use with higher viscosity and cold fluids.

    How is the H2GO handled?

    Simple and reliable H2GO handling takes place via a programmable logic controller PLC used in combination with a touch screen control panel.

    What are the advantages of using H2GO?

    Advantages of using H2GO include:

    • Extremely low residual water and gas levels in operating fluids
    • Longer oil change intervals
    • Improved component service life
    • Greater machine availability
    • Reduction in life cycle cost
    How can the H2GO clean fluids that have particulate contamination?

    Fluids that have particulate contamination can be cleaned when the H2GO is used in combination with HYDAC offline filtration systems.

    Can the H2GO treat fluids that have a build-up of degradation products such as varnish?

    Fluids that have a build-up of degradation products like varnish can be treated by the H2GO in parallel with the Varnish Elimination Unit (VEU-AU).

    What are the H2GO’s flow rates at 50Hz?

    The H2GO’s flow rates at 50Hz are 8.7-27l/min (automatically variable).

    What is the H2GO’s filter bypass pressure?

    The H2GO’s filter bypass pressure is 3.5 bar.

    What is the H2GO’s operating pressure?

    The H2GO’s operating pressure is up to 15 bar.

    What is the H2GO’s viscosity range?

    The H2GO’s viscosity range is 12 … 320 mm2/sec.
